1. Machining
Drill your 6mm PEANUT® 3 holes and machine your PEANUT® Slots with the PEANUT® Cutter
2. Insert the PEANUT® 3
Use a mallet or hammer to insert the PEANUT® 3 flush
3. Join your furniture
Simple connect your furniture together
How it Works
The PEANUT 3 is available in two sizes. Each are single component, invisible connectors and provide the optimum solution for large scale manufacturers.
Key Benefits
Design
The PEANUT 3 is made of a strong reinforced plastic and has rows of teeth around the dowel end to provide gripping strength when inserted.
Self-clamping, invisible connector
Packs flat when pre-inserted
Creates an incredibly strong joint
Quick and simple assembly
Ability to reassemble many times
Designed from glass fibre reinforced nylon
45° joints for 18mm+ material, 90° joints for 15.3mm+ material
Ideal for boring and insertion machines
Tooling Requirements
They are designed for fast assembly and compatible with end drilling machines, auto-insertion machines and large scale production line insertion machines.
The standard size PEANUT 3 component is designed for perfect 45° and face-to-face connections. Meanwhile, the PEANUT 3 Long provides an optimal solution for 90° and end-to-end connections.
Glue is recommended to be inserted within each 6mm hole and this allows all panels made with PEANUT components to be packed flat and depending on the tightness of the joint, can be reassembled
The component is solid filled, meaning that it has no holes for screws or pins. Depending on the application, glue can be used to further increase the grip strength of the component. The PEANUT® 3 has been designed with a shoulder to stop over-insertion and is perfectly calibrated for a tight joint.
The PEANUT® head has been specially designed to maximise ease of assembly and joint strength. Due to its dome shape, the PEANUT® head smoothly slides along the slot created by the T-shaped PEANUT® Cutter.
In assembly, the PEANUT head rides over the lip of the PEANUT® slot and slides to the end, this action creates a strong clamping force, pulling the two panels together from the inside.
AWI Certification
Our PEANUT system has undergone the highly accredited AWI certification program and has achieved and been tested at Duty Level 3 for Base, Tall and Wall Cabinets.
Scroll down towards the bottom of this page to view the downloads section, where report summaries can be found for the testing that was completed on the Base, Tall and Wall Cabinets.
PEANUT® 3
the optimum insertion solution
